R3204 Rigid Shaft Coupling - One Piece

Name: R3204.32-10-14
Brand: WC
SKU: R3204.32-10-14
Price: 25.45 EUR
Availability: OutOfStock

Stainless, short, material: Stainless steel

Article properties

Order No.

R3204.32-10-14

d₁ tol. H7/H8

d₂ tol. H7/H8

d₃

d₄

M 4

l₁

Weight g

l₂

7.75

l₃

1.0

w₁

Static torque Nm

rpm max.

4800

Moment of inertia kg·m²

7,1x10^-6

Torque screw to Nm

2.5

Weight g

See full product selection

£ 25.45 per unit (click for quantity discounts)

Ready to despatch 0
Need more? Manufactured within 21 working days from order.
Typical UK delivery charge: £13.50.
Confirmed at checkout.

Buy more & save with our quantity discounts

Units	Price/unit after discount	Applied Discount
1-4	£ 25.45	0%
5-9	£ 22.91	10%
10-19	£ 21.63	15%
20-49	£ 19.09	25%
50+	£ 16.54	35%

Download product datasheet

Technical & Application

Material

Stainless steel (A2).

Technical Notes

To fit h7 and h8 tolerance shafts.
Maintenance free, excellent anti-oil and corrosion resistance.
Reciprocating torque is quarter static torque.
Rotational torque is half static torque.

Important Notes

Different bore sizes available on request.
For keyways, please add "-KW" suffix when ordering.
