Push/Pull dashpots
Graphite
L4574 Push/Pull Dashpot
0.627" bore, material: Graphite
Order No.
L4574.E3000-PS
Stroke
3,0"
Damping direction
Push
Rod end linkage
1/4" Ball
Bore dia.
0,627"
Piston rod
Aluminium
Pull damping force
max.
N
18
Push damping force
max.
N
13
Body length
3,781"
£ 215.90 per unit (click for quantity discounts)
Ready to despatch 0
Need more? Please call us.
Need more? Please call us.
| Units | Price/unit after discount | Applied Discount |
| 1-4 | £ 215.90 | 0% |
| 5-19 | £ 194.31 | 10% |
| 20-39 | £ 172.72 | 20% |
| 40-99 | £ 151.13 | 30% |
| 100+ | £ 129.54 | 40% |
Technical & Application
Material
Graphite carbon piston.
Annealed borosilicate glass cylinder.
Precision fire-polished bore.
Stainless steel piston rod (AISI 304) or Aluminium 2024-T4
Technical Notes
Damping coefficient = 0-1,75 N/(mm/s).
Friction coefficient = 0.2.
Force without side load: <1g.
Operating temperature range: -55°c
Operating temperature range: -55° to 150°c.
*If operating temperature is above +70°c, please advise at time of ordering.
Important Notes
Mounting data:
Mounting hole:
Rectangular = 0.312 x 0.375 (8mm x 10mm)
Round = 0.375" (10mm)
Suggested mounting bracket thickness = 0.06 - 0.093 (1.52mm - 2.36mm)
Mounting nut torque:
Head = 4-8 in-lb (0.45 - 0.90 Nm)
Rod end = 2-5 in-lb (0.23-0.56 Nm)
Full stroke is obtained with customer held mounting tolerance of ±0.015" (0.38mm).
1/4" ball joint linkage option only available with aluminium rod.
Level of damping is adjustable by hand. If you know the level of damping required we can pre-set this in the factory.
