Steel A-V Mounts
P2103 Anti-vibration Mounts
material: Steel
Order No.
P2103.220-060
Type
Type 2
d1
230
d2
M24
d3
19.0
h1
105.0
l1
180
l2
220
Axial load
max.
kgf
3400
Shore
60
£ 481.49 per unit (click for quantity discounts)
Ready to despatch 0
Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout.
Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout.
| Units | Price/unit after discount | Applied Discount |
| 1-19 | £ 481.49 | 0% |
| 20-49 | £ 409.27 | 15% |
| 50-99 | £ 361.12 | 25% |
| 100-199 | £ 312.97 | 35% |
| 200-499 | £ 288.89 | 40% |
| 500+ | £ 240.75 | 50% |
Technical & Application
Material
Rubber on silver zinc plated steel (rubber hardness - 60 Shore A).
Technical Notes
Provides an elastic support mechanism for equipment isolation. Used in generator sets, motors, pumps and most other machine parts.
Please note for marine applications or very demanding use we recommend the mounts with 'fail-safe' features part numbers , P2101 and P2102.
Tips
These are a very popular anti-vibration mount for light to heavy duty applications.
Take the total weight of the load to be supported, divide it by the number of mounts to be used and select an appropriate mount from the above table. Type 2 is 'fail-safe'.
