L1779.A4 Shaft End Supports

Name: L1779.02-160-A4
Brand: WC
SKU: L1779.02-160-A4
Price: 198.09 EUR
Availability: OutOfStock

316 series stainless steel, material: A4 Stainless

Article properties

Order No.

L1779.02-160-A4

Type

d₁ tol. G7

d₂

M 6

d₃

M 3

h₁

h₂

h₃

h₄

h₅

l₁

l₂

w₁

w₂

See full product selection

£ 198.09 per unit (click for quantity discounts)

Ready to despatch 0
Need more? Manufactured within 14 working days from order.
Typical UK delivery charge: £13.50.
Confirmed at checkout.

Buy more & save with our quantity discounts

Units	Price/unit after discount	Applied Discount
1+	£ 198.09

Download product datasheet

Download FREE CAD

Technical & Application

Material

Stainless steel (AISI 316, 1.440).

Technical Notes

For mounting of standard shaft diameters, tolerance h6.
