Clamp Cleats
P0292 Clamp Cleats
material: Stainless steel
Alternative products you may wish to consider
£ 4.93 per unit (click for quantity discounts)
£ 5.45 per unit (click for quantity discounts)
£ 4.93 per unit (click for quantity discounts)
£ 5.45 per unit (click for quantity discounts)
£ 6.22 per unit (click for quantity discounts)
£ 4.79 per unit (click for quantity discounts)
£ 6.16 per unit (click for quantity discounts)
£ 5.45 per unit (click for quantity discounts)
£ 4.90 per unit (click for quantity discounts)
£ 5.39 per unit (click for quantity discounts)
h1
±6,08
d1
h2
±0,08
h3
h4
l1
+0|-0.8
w1
w2
+0|-0.15
| Price & Availability | Article | h1 ±6,08 | d1 | h2 ±0,08 | h3 | h4 | l1 +0|-0.8 | w1 | w2 +0|-0.15 | ||||||
| P0292.079 | 0.79 | M3 | 1.02 | 1.80 | 1.73 | 8.0 | 9.90 | 3.18 | |||||||
£ 4.93 per unit (click for quantity discounts) Ready to despatch 0 Need more? Please call us.
h1
±6,08 0.79 d1 M3 h2
±0,08 1.02 h3 1.80 h4 1.73 l1
+0|-0.8 8.0 w1 9.90 w2
+0|-0.15 3.18 | |||||||||||||||
| P0292.157 | 1.57 | M3 | 1.02 | 2.59 | 1.73 | 8.0 | 9.90 | 3.18 | |||||||
£ 5.45 per unit (click for quantity discounts) Ready to despatch 0 Need more? Please call us.
h1
±6,08 1.57 d1 M3 h2
±0,08 1.02 h3 2.59 h4 1.73 l1
+0|-0.8 8.0 w1 9.90 w2
+0|-0.15 3.18 | |||||||||||||||
| P0292.158 | 1.58 | M3 | 1.27 | 2.84 | 1.73 | 10.0 | 9.90 | 3.18 | |||||||
£ 4.93 per unit (click for quantity discounts) Ready to despatch 18 Need more? Please call us.
h1
±6,08 1.58 d1 M3 h2
±0,08 1.27 h3 2.84 h4 1.73 l1
+0|-0.8 10.0 w1 9.90 w2
+0|-0.15 3.18 | |||||||||||||||
| P0292.159 | 1.57 | M3 | 1.60 | 3.18 | 1.73 | 10.0 | 9.90 | 3.18 | |||||||
£ 5.45 per unit (click for quantity discounts) Ready to despatch 0 Need more? Please call us.
h1
±6,08 1.57 d1 M3 h2
±0,08 1.60 h3 3.18 h4 1.73 l1
+0|-0.8 10.0 w1 9.90 w2
+0|-0.15 3.18 | |||||||||||||||
| P0292.198 | 1.98 | M3 | 1.60 | 3.58 | 1.73 | 10.0 | 9.90 | 3.18 | |||||||
£ 6.22 per unit (click for quantity discounts) Ready to despatch 0 Need more? Please call us.
h1
±6,08 1.98 d1 M3 h2
±0,08 1.60 h3 3.58 h4 1.73 l1
+0|-0.8 10.0 w1 9.90 w2
+0|-0.15 3.18 | |||||||||||||||
| P0292.236 | 2.36 | M3 | 1.02 | 3.38 | 1.73 | 10.0 | 9.90 | 3.18 | |||||||
£ 4.79 per unit (click for quantity discounts) Ready to despatch 14 Need more? Please call us.
h1
±6,08 2.36 d1 M3 h2
±0,08 1.02 h3 3.38 h4 1.73 l1
+0|-0.8 10.0 w1 9.90 w2
+0|-0.15 3.18 | |||||||||||||||
| P0292.237 | 2.36 | M3 | 1.27 | 3.63 | 1.73 | 10.0 | 9.90 | 3.18 | |||||||
Ready to despatch 0 Need more? Please call us.
h1
±6,08 2.36 d1 M3 h2
±0,08 1.27 h3 3.63 h4 1.73 l1
+0|-0.8 10.0 w1 9.90 w2
+0|-0.15 3.18 | |||||||||||||||
| P0292.238 | 2.36 | M3 | 1.60 | 3.96 | 1.73 | 10.0 | 9.90 | 3.18 | |||||||
£ 6.16 per unit (click for quantity discounts) Ready to despatch 8 Need more? Please call us.
h1
±6,08 2.36 d1 M3 h2
±0,08 1.60 h3 3.96 h4 1.73 l1
+0|-0.8 10.0 w1 9.90 w2
+0|-0.15 3.18 | |||||||||||||||
| P0292.318 | 3.18 | M3 | 1.27 | 4.45 | 1.73 | 10.0 | 9.90 | 3.18 | |||||||
£ 5.45 per unit (click for quantity discounts) Ready to despatch 190 Need more? Please call us.
h1
±6,08 3.18 d1 M3 h2
±0,08 1.27 h3 4.45 h4 1.73 l1
+0|-0.8 10.0 w1 9.90 w2
+0|-0.15 3.18 | |||||||||||||||
| P0292.396 | 3.96 | M3 | 1.02 | 4.98 | 1.73 | 10.0 | 9.90 | 3.18 | |||||||
£ 4.90 per unit (click for quantity discounts) Ready to despatch 2 Need more? Please call us.
h1
±6,08 3.96 d1 M3 h2
±0,08 1.02 h3 4.98 h4 1.73 l1
+0|-0.8 10.0 w1 9.90 w2
+0|-0.15 3.18 | |||||||||||||||
| P0292.572 | 5.72 | M3 | 1.60 | 7.32 | 1.73 | 12.0 | 9.90 | 3.18 | |||||||
£ 5.39 per unit (click for quantity discounts) Ready to despatch 0 Need more? Please call us.
h1
±6,08 5.72 d1 M3 h2
±0,08 1.60 h3 7.32 h4 1.73 l1
+0|-0.8 12.0 w1 9.90 w2
+0|-0.15 3.18 | |||||||||||||||
| P0292.635 | 6.35 | M3 | 1.60 | 7.92 | 1.73 | 16.0 | 9.90 | 3.18 | |||||||
Ready to despatch 0 Need more? Please call us.
h1
±6,08 6.35 d1 M3 h2
±0,08 1.60 h3 7.92 h4 1.73 l1
+0|-0.8 16.0 w1 9.90 w2
+0|-0.15 3.18 | |||||||||||||||
Technical & Application
Material
Stainless steel (A4, AISI316, DIN 1.4401), with nylon insert.
Supplied with A2 (AISI303) stainless steel screw (screws not supplied with P1092.019, .020, or .026).
Technical Notes
Quick release, faster clamping and self-locking.
Tips
Bolt circle: use the larger of the following two bolt circles:
add 6,86 to max. flange diameter or add 10,16 to max. groove base diameter.
