R5163 Spur Gears - Module 1

Name: R5163.100-016
Brand: WC
SKU: R5163.100-016
Price: 38.11 EUR
Availability: OutOfStock

stainless steel - 14-16 teeth, material: Stainless steel

Article properties

Order No.

R5163.100-016

Module

m 1

No. of teeth z

Pitch dia. d₁

d₂

w₁

d₃ tol. H8

d₄

l₁

l₂

Thread d₅

2xM 4

Torque max. Nm

2.10

Weight g

40.5

See full product selection

£ 38.11 per unit (click for quantity discounts)

Ready to despatch 0
Need more? Manufactured within 7 working days from order.
Typical UK delivery charge: £13.50.
Confirmed at checkout.

Buy more & save with our quantity discounts

Units	Price/unit after discount	Applied Discount
1-4	£ 38.11	0%
5-19	£ 34.30	10%
20-39	£ 30.49	20%
40-99	£ 26.68	30%
100+	£ 22.87	40%

Download product datasheet

Technical & Application

Material

Stainless steel (SUS 304, JIS G 4303).
Accuracy to JIS B 1702-1 (ISO) class 9.

Technical Notes

20° pressure angle, full depth tooth.
Amount of backlash when assembling gears = 0,06 - 0,12mm.

Tips

For stainless steel module 1 gears with 17-120 teeth, see R5165.
Max. allowable torque (Nm) is based on standard operating conditions (see technical pages) with a safety factor of 1.2. For non standard applications apply a suitable safety factor depending on frequency of use, type of working etc.
