Spring Vibration Damper
Steel
P2456 Spring Vibration Damper five spring
five spring, material: Steel
Alternative products you may wish to consider
Spring colour
Blue
l1
280
h
136
d
16
w1
150
l2
251
l3
290
l4
322
w2
156
Compression
max.
30
Load
max.
kgf
750
Weight
kg
8.50
£ 369.19 per unit (click for quantity discounts)
Spring colour
White
l1
280
h
136
d
16
w1
150
l2
251
l3
290
l4
322
w2
156
Compression
max.
30
Load
max.
kgf
1000
Weight
kg
8.69
£ 378.27 per unit (click for quantity discounts)
Spring colour
Black
l1
280
h
136
d
16
w1
150
l2
251
l3
290
l4
322
w2
156
Compression
max.
30
Load
max.
kgf
1250
Weight
kg
9.16
£ 384.49 per unit (click for quantity discounts)
Spring colour
Cream
l1
280
h
136
d
16
w1
150
l2
251
l3
290
l4
322
w2
156
Compression
max.
30
Load
max.
kgf
1750
Weight
kg
10.03
£ 447.55 per unit (click for quantity discounts)
Spring colour
Light Grey
l1
350
h
136
d
18
w1
200
l2
315
l3
360
l4
396
w2
206
Compression
max.
18
Load
max.
kgf
2500
Weight
kg
15.71
£ 839.62 per unit (click for quantity discounts)
Spring colour
Green
l1
350
h
136
d
18
w1
200
l2
315
l3
360
l4
396
w2
206
Compression
max.
18
Load
max.
kgf
3750
Weight
kg
18.05
£ 1,018.40 per unit (click for quantity discounts)
Spring colour
l1
h
d
w1
l2
l3
l4
w2
Compression
max.
Load
max.
kgf
Weight
kg
| Price & Availability | Article | Spring colour | l1 | h | d | w1 | l2 | l3 | l4 | w2 | Compression max. | Load max. kgf | Weight kg | ||||||||||||||||||
| P2456.016-0750 | Blue | 280 | 136 | 16 | 150 | 251 | 290 | 322 | 156 | 30 | 750 | 8.50 | |||||||||||||||||||
£ 369.19 per unit (click for quantity discounts) Ready to despatch 0 Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout.
Spring colour Blue l1 280 h 136 d 16 w1 150 l2 251 l3 290 l4 322 w2 156 Compression
max. 30 Load
max.
kgf 750 Weight
kg 8.50 | |||||||||||||||||||||||||||||||
| P2456.016-1000 | White | 280 | 136 | 16 | 150 | 251 | 290 | 322 | 156 | 30 | 1000 | 8.69 | |||||||||||||||||||
£ 378.27 per unit (click for quantity discounts) Ready to despatch 0 Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout.
Spring colour White l1 280 h 136 d 16 w1 150 l2 251 l3 290 l4 322 w2 156 Compression
max. 30 Load
max.
kgf 1000 Weight
kg 8.69 | |||||||||||||||||||||||||||||||
| P2456.016-1250 | Black | 280 | 136 | 16 | 150 | 251 | 290 | 322 | 156 | 30 | 1250 | 9.16 | |||||||||||||||||||
£ 384.49 per unit (click for quantity discounts) Ready to despatch 0 Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout.
Spring colour Black l1 280 h 136 d 16 w1 150 l2 251 l3 290 l4 322 w2 156 Compression
max. 30 Load
max.
kgf 1250 Weight
kg 9.16 | |||||||||||||||||||||||||||||||
| P2456.016-1750 | Cream | 280 | 136 | 16 | 150 | 251 | 290 | 322 | 156 | 30 | 1750 | 10.03 | |||||||||||||||||||
£ 447.55 per unit (click for quantity discounts) Ready to despatch 0 Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout.
Spring colour Cream l1 280 h 136 d 16 w1 150 l2 251 l3 290 l4 322 w2 156 Compression
max. 30 Load
max.
kgf 1750 Weight
kg 10.03 | |||||||||||||||||||||||||||||||
| P2456.018-2500 | Light Grey | 350 | 136 | 18 | 200 | 315 | 360 | 396 | 206 | 18 | 2500 | 15.71 | |||||||||||||||||||
£ 839.62 per unit (click for quantity discounts) Ready to despatch 0 Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout.
Spring colour Light Grey l1 350 h 136 d 18 w1 200 l2 315 l3 360 l4 396 w2 206 Compression
max. 18 Load
max.
kgf 2500 Weight
kg 15.71 | |||||||||||||||||||||||||||||||
| P2456.018-3750 | Green | 350 | 136 | 18 | 200 | 315 | 360 | 396 | 206 | 18 | 3750 | 18.05 | |||||||||||||||||||
£ 1,018.40 per unit (click for quantity discounts) Ready to despatch 0 Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout.
Spring colour Green l1 350 h 136 d 18 w1 200 l2 315 l3 360 l4 396 w2 206 Compression
max. 18 Load
max.
kgf 3750 Weight
kg 18.05 | |||||||||||||||||||||||||||||||
Technical & Application
Material
High tensile steel with sylomer anti-slide base.
Technical Notes
The sylomer mat that these dampers incorporate, isolates the mid-high frequency vibrations which are transmitted through the coils of the metal springs.
Tips
These are used in sectors such as air compressors, pump and pumping equipment and acoustic isolation of premises.
