Module 1.5
Spur Gears
R5198 Spur Gears - Module 1.5
carbon steel - 8-10 teeth, material: Steel
Order No.
R5198.150-10
Module
No. of teeth z
10
Pitch dia. d1
Shifted Gear *
d2
19
w1
18
d3
tol. H9
19
l1
90
l2
24
l3
48
Torque
max.
Nm
14.23
Weight
g
190.5
£ 31.99 per unit (click for quantity discounts)
Ready to despatch 8
Need more? Manufactured within 7 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout.
Need more? Manufactured within 7 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout.
| Units | Price/unit after discount | Applied Discount |
| 1-4 | £ 31.99 | 0% |
| 5-19 | £ 28.79 | 10% |
| 20-39 | £ 25.59 | 20% |
| 40-99 | £ 22.39 | 30% |
| 100+ | £ 19.19 | 40% |
Technical & Application
Material
Carbon steel (ISO C45).
Accuracy to JIS B 1702-1 (ISO) class 8-9.
Technical Notes
20° pressure angle, full depth tooth. Amount of backlash when assembling gears = 0,06 - 0,15mm. Rack shift coefficient x = 0.5.
Tips
For module 1.5 hubless steel gears with 60-100 teeth see R5194. For gears with 8-10 teeth see R5198 & R5199, for gears with 12-14 teeth see R5200,
for gears with 15-100 teeth See R5201 & R5204 (reduced weight version).
Max. allowable torque (Nm) is based on standard operating conditions (see technical pages) with a safety factor of 1.2. For non standard applications apply a suitable safety factor depending on frequency of use, type of working etc.
