P2183 Precision Adjuster

Name: P2183.106-200-ZP
Brand: WC
SKU: P2183.106-200-ZP
Price: 159.45 EUR
Availability: OutOfStock

with locking nut, material: Steel

Article properties

Order No.

P2183.106-200-ZP

Material

Steel

For bolt

M20

h₁

106

h₂

h₃

d₁

d₂

22.0

d₃

M50x1,5

Load with bolt max. kN

210.00

Load w/o bolt max. kN

330.00

See full product selection

£ 159.45 per unit (click for quantity discounts)

Ready to despatch 0
Need more? Manufactured within 10 working days from order.
Typical UK delivery charge: £13.50.
Confirmed at checkout.

Buy more & save with our quantity discounts

Units	Price/unit after discount	Applied Discount
1-4	£ 159.45	0%
5-9	£ 143.51	10%
10-19	£ 135.53	15%
20-49	£ 119.59	25%
50+	£ 103.64	35%

Download product datasheet

Download FREE CAD

Technical & Application

Material

Steel (type 42 CrMo4 V, 1.7225) zinc plated or stainless steel A1 (A4 on request).

Technical Notes

After setting the height, the structure can be bolted down using a suitable 8,8 strength bolt.
The net load that the unit can carry is the maximum load less the tightening torque recommended for the bolt.
Designed for applications with a dynamic load, or where no fasteners are used. The locknut enables locking of the adjuster in a pre-set position.
