L3524 Multi-Axes Stepper Controllers
material: Aluminium
Order No.
L3524.ST3X-E
No. of axes
Three stepper
Encoder
Yes
Voltage for stepper driver
24V DC
Output current continuous
Amps
-
Output current peak
Amps
3
£ 9,088.20 per unit (click for quantity discounts)
Ready to despatch 0
Need more? Please call us.
Need more? Please call us.
| Units | Price/unit after discount | Applied Discount |
| 1-1 | £ 9,088.20 | 0% |
| 2-2 | £ 8,179.38 | 10% |
| 3-4 | £ 7,724.97 | 15% |
| 5+ | £ 7,270.56 | 20% |
Technical & Application
Material
Incorporates a Motorola 32 bit microcomputer. Configurable to run up to four stepper or servo motors. For 2/4 phase bipolar stepper motors.
Power input 100-240V AC, 47-63 Hz.
Technical Notes
Communication: RS-485 (up to 19,2 kbps) 10 Base-T Ethernet.
Encoder feedback: High speed differential inputs up to 12Mhz.
Number of I/O: 4 x inputs, 4 x outputs.
Program and data storage: 1000 lines x 80 characters. 510 variables. 8000 array elements in up to 30 arrays.
Easy programming with simple command language. Communication drivers are available for Windows, .NET, Mac OSX and Linux.
Operating temperature 0°C to 50°C, humidity 20-95%.
Tips
Can be plugged into, and control up to four axes simultaneously. Comes with cables and software. Simple plug and play system via USB port of your laptop or PC.
Micro-stepping is the number of steps per revolution of the motor output shaft.
