Cross Roller Slides
stainless
L1022.web Stainless Cross Roller Slides
smaller sizes, material: Stainless Steel
Order No.
L1022.100-130
l1
210
Stroke
130
Static load C0
max.
kN
36.8
w1
100
l2
31
h1
31
Roller
6.0
l3
50
l4
50
l5
148
l6
30
w2
50
w3
25
Weight
kg
4.51
w4
42
w5
29
w6
26
w7
37
h2
31
h3
16
h4
15
d1
M6
Allowable load
max.
kN
12.2
Dyn. load C
max.
kN
21.6
Moment Mx
max.
Nm
552
Moment My
max.
Nm
773
Moment Mz
max.
Nm
828
£ 758.68 per unit (click for quantity discounts)
Ready to despatch 0
Need more? Manufactured within 21 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout.
Need more? Manufactured within 21 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout.
| Units | Price/unit after discount | Applied Discount |
| 1-4 | £ 758.68 | 0% |
| 5-9 | £ 682.81 | 10% |
| 10-19 | £ 644.88 | 15% |
| 20-49 | £ 569.01 | 25% |
| 50+ | £ 493.14 | 35% |
Technical & Application
Material
Body stainless steel (440C), nickel plated apart from rail V groove. Retainer stainless (304), rollers stainless (440C).
Technical Notes
Carriage top parallelism 3µ.
Carriage side parallelism 5µ.
Product Datasheets
CAD files
Application images
